Technical Specification
|
General |
|
|
Welding processes |
MIG / MAG - PULSED MIG / MAG - MMA - TIG DC HF - TIG DC Lift |
|
Materials |
Carbon steels - Stainless Steels - Aluminium - Copper |
|
Dimensions L x W x H |
620 x 270 x 460 mm |
|
Weight |
25.0 kg |
|
|
|
|
Power supply |
|
|
Voltage (50/60 Hz) |
3 x 400 / 230 V ± 15% |
|
Maximum input power |
9.1 / 9.1 kVA |
|
Maximum input current |
13.1 / 22.8 A |
|
Power factor PF |
0.94 / 0.96 |
|
Efficiency |
88 / 86 % |
|
Slow blow line fuse |
16 / 20 A |
|
Open circuit voltage |
92 Vdc |
|
IP protection rate |
IP23S |
|
Insulation class |
H |
|
Power supply cable |
4 x 2.5 mm2 - 5 m |
|
|
|
|
Welding |
|
|
Adjustment range |
3 - 270 A |
|
Duty cycle MIG / MAG - 40 °C |
45 % - 270 A 60 % - 250 A 100 % - 230 A |
|
Duty cycle MIG / MAG - 25 °C |
100 % - 270 A |
|
Ø Wire diameter |
1.0 - 1.2 mm (opz 0.6 - 1.2) |
|
Ø Flux cored wire |
1.2 - 1.6 mm |
|
Ø Aluminiumwire |
0.8 - 1.2 mm |
|
Wire speed |
0.5 - 22 m / min |
|
N° rolls |
2 (4 opz) |
|
Wire spool diameter |
Ø 200 / 300 mm |
|
Synergic program |
60 |
|
Welding program memory location |
64 |
|
U/D TIG Torch compatible |
YES |
|
Digital TIG Torch compatible |
YES |
|
U/D MIG/MAG torch compatible |
YES |
|
PUSH PULL torch compatible |
YES |
|
Remote Control compatible |
YES |
|
Standard EasyArc |
YES |
Technicalities
- 'Green @ wave' inverter technology for high energy efficiency and perfect control over all welding phases
- Heavy duty and enviromental conditions, high service life
- CAN fieldbus digital communication protocol system (very high speed and high reliability digital communication)
- Software based controls can be upgraded as new features become available
- Reduced dimensions and compact construction
- High temperature, shockproof, abrasion resistant plastic case
- Air flow ducting and fully encapsulated PC board to avoid dust contamination
- Linear controlled fan on demand
- Energy-saving inverter technology (built-in P.F.C. - power factor controller)
- Built-in wire feeder unit (2 / 4 rolls drive)
- Fully voestalpine Böhler Welding designed wire drive unit
- Ø 200 / 300 mm wire spool compatible
- Welding polarity switch device
- Full digital and user-friendly LCD graphic display control panel
- Welding parameters digital display
- Last job settings auto-storage at switch-off
- Totally programmable user interface
- Programmable welding operations safety limits
- Lock-unlock function key protected by password
- Ideal for stick welding with multiple types of popular electrodes
- Built-in adjustable arc control features (hot start, arc force, antisticking)
- Synergic setting for optimal stick welding with all types of electrodes
- Precise arc striking and high stability arc
- 2 / 4 step operating mode
- Arc dynamic adjustment
- Perfect arc ignition (soft start - motor slope)
- Burn-back and droplet detachment correction
- Crater filler operating mode
- Synergic operations from databank (60 pre-set programs)
- Wire speed (0,5 - 22,0 m / min), amperage and piece thickness adjustment
- Spot welding mode
- Intermittent welding mode
- MIG / MAG bilevel
- Selco Up / Down torch compatible (welding current adjustment)
- Smart slope control
- Euro adaptor - U/D MIG/MAG torch compatible
- Remote control compatible
- WU cooling unit compatible
- Controlled cooling operations
